Compatibility:
Front axle: 12x100 thru axle, easily convertible to quick release with included adapters. Not compatible with 15mm through axles.
Rear axle: 12mm thru axle, convertible to Quick Release with included adapters
Freewheel: Shimano/Sram, convertible to Campagnolo and XD-R with optional driver bodies
Compatible Adapters and freewheel bodies
ID360 Shimano / Sram freewheel body (V3430101- Delivered on the wheel)
ID360 XD-R freewheel body (V2580101)
ID360 Campagnolo freewheel body (V3440101)
ID360 Shimano / Sram Light freewheel body (V3850101)
12x135 rear axle adapters (V2510901)
12 to 9mm rear adapter for quick release (V2510801- Delivered with the wheel)
12x142 rear axle adapters (V2510701- Delivered with the wheel)
12mm front hub cap (V2680501 - Delivered with the wheel)
12 to 9mm front adapter for quick release (V2680301 - Delivered with the wheel)
Weight:
Pair without tyre: 1905 grams
Front without tyre: 870 grams
Rear without tyre: 1035 grams
Hubs:
Front: Quick release and 12x100 through axle compatible
Auto adjust sealed cartridge bearings (QRM Auto), front and rear
Rear: Quick Release, 12x142 and 12x135 compatible
Freewheel: Instant Drive 360
Front and rear bodies: aluminum
Axle material: aluminum
Intended Use:
Max. Pressure: 23mm 8.7 bars - 125 psi, 25/28mm 7.7 bars - 110 psi
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
ASTM CATEGORY 2 : road and offroad with jumps less than 15cm
Recommended tyre sizes: 25 to 32 mm
Rims:
ETRTO size: 622x17C
Drilling: traditional
Height: 21 mm
Internal width: 17 mm
Disc brake specific profile
Valve hole diameter: 6.5 mm
Joint: pinned
Material: S6000 Aluminum
Tyre: clincher
Spokes:
Nipples: steel, ABS
Material: steel
Lacing: front and rear crossed 2
Count: 24 front and rear
Shape: straight pull, round
DELIVERED WITH:
Rear QR adapters for Instant Drive 360
Front QR adapters
Rim tape
User guide
