Compatibility
Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters (not available in Germany)
Front axle : 12mm thru axle. Optional : Easily convertible to quick release with adequate adapters, convertible to 15mm with complete axle replacement
Freewheel: Shimano/Sram, convertible to Campagnolo and XD-R with optional driver bodies
Weight
Pair without tyre: 1720 grams
Front without tyre: 795 grams
Rear without tyre: 925 grams
Hubs
Front : adjustable sealed cartridge bearings (QRM+), Rear : auto adjust sealed cartridge bearings (QRM Auto)
Freewheel: Instant Drive 360
Front and rear bodies: aluminum
Axle material: aluminum
Intended Use
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
ASTM CATEGORY 2 : road and offroad with jumps less than 15cm
Max. Pressure: 30mm 5.8 bars - 85 PSI / 40mm 4.5 bars - 65 PSI
Recommended tyre sizes: 60mm to 81mm (2.35"" to 3.2"")
Rims
Height: 22 mm
ETRTO size: 622x22TSS ROAD
Internal width: 22 mm
Weight reduction: ISM 4D
Disc brake specific profile
Valve hole diameter: 6.5 mm
Tyre: UST Tubeless and tubetype
Drilling: Fore
Joint: SUP
Material: Maxtal
Spokes
Material: steel
Shape: straight pull, bladed
Lacing: front crossed 2, rear Isopulse
Nipples: Fore integrated aluminum
Count: 24 front and rear
Tyre
Dimensions: 30-622 or 40-622 (700x30c or 700x40c)
Yksion Elite Allroad or Yksion Elite Allroad XL
UST Tubeless Ready
Breaker: Polyamide, from bead to bead
Casing: 120 TPI
Front and Rear Tread: Single Compound
Versions
Disc standard : 6 Bolts or Center Lock(R)
Color: Black only
DELIVERED WITH
Front 12 mm adapters
Rear 12x142mm adapters for Instant Drive 360
Mavic tyre sealant (rear wheel)
Specific disc bolts
UST valve and accessories
User guide
