Rims
Material: 3K carbon fibers
Height: 45 mm
Drilling: traditional
Disc brake specific profile
Valve hole diameter: 6.5 mm
Tyre: UST Tubeless and tubetype
Internal width: 19 mm
ETRTO size: 622x19TC Road
Use with Mavic Tubeless Tape
Spokes
Material: steel
Shape: straight pull, flat, double butted
Nipples: steel, ABS
Count: 24 front and rear
Lacing: front and rear crossed 2
Hubs
Front and rear bodies: aluminum
Axle material: aluminum
Auto adjust sealed cartridge bearings (QRM Auto), front and rear
Freewheel: Instant Drive 360
Front: Quick release and 12x100 through axle compatible
Rear: Quick Release, 12x142 and 12x135 compatible
Tyre
Yksion Pro UST
UST Tubeless Ready
Front and Rear Tread: 11 Storm single compound
Casing: 127 TPI
Breaker: Polyamide, from bead to bead
Dimension: 25-622 (700x25c)
Versions
Color: Black only
Disc standard: Center Lock(R) only
Compatibility
Freewheel: Shimano/Sram, convertible to Campagnolo and XD-R with optional driver bodies
Front axle: 12x100 thru axle, easily convertible to quick release with included adapters. Not compatible with 15mm through axles.
Rear axle: 12mm thru axle, convertible to Quick Release with included adapters
Compatible Adapters and freewheel bodies (Sold separately)
12 to 9mm front adapter for quick release ([V2680301] - Delivered with the wheel)
12mm front hub cap ([V2680501] - Delivered with the wheel)
12x142 rear axle adapters ([V2510701] - Delivered with the wheel)
12 to 9mm rear adapter for quick release ([V2510801] - Delivered with the wheel)
12x135 rear axle adapters ([V2510901])
ID360 Shimano / Sram Light freewheel body ([V3850101])
ID360 Campagnolo freewheel body ([V3440101])
ID360 XD-R freewheel body ([V2580101])
ID360 Shimano / Sram freewheel body ([V3430101] - Delivered on the wheel)
Delivered with
Mavic tyre sealant (rear wheel)
Tyre sealant syringe
Front QR adapters
Rear QR adapters for Instant Drive 360
UST valve and accessories
Tubeless rim tape
User guide
Label
SSC
Intended use
ASTM CATEGORY 1 : road only
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
Recommended tyre sizes: 25 to 32 mm
Max. Pressure: see indication on wheel and tyre. If they differ, use the lower of the 2
Filters
brake type: disc
field: rolling
rim profile: medium
rim: carbon
tubeless: yes
tyre type: clincher
tyre type: tubeless
weight: 1601g to 1700g
Efficiency & rigidity
Instant Drive 360
UST Tubeless Ready
11 Storm
QRM Auto
Weight Front: 760g
Weight Pair: 1650g
Weight Rear: 890g
